SWING 53.i - Coding & Marking Electronic Systems

DESCRIPTION
The "thermal transfer" SWING 53.i electronic printer is able to print automatically and directly on the plastic film used on packaging machines.
It assure extremely flexible, high quality printing for coding of various production lots with variable texts, bar codes and logos.
Marking directly on the production line makes it possible to customize the product when this is packaged, thus eliminating the need for a large stock of pre-printed rolls.
The SWING is easy to install as it can be used to replace the standard hot stamping and rotary coders without modifying the machine.

TECHNICAL DATA

PRINTING
Technology: with thermal transfer ribbon
Max print area: mm 53x75
Resolution: 12 dots/mm (300 dpi)
Print speed: up to 300 mm/sec
Print margins: programmable
Print intensity: programmable

POWER
Electrical: 220 / 110 Vac 50 / 60 Hz
Power: 300 VA max
Compressed air: 6 Bar Max 10 lt/min

MACHINE DIMENSIONS
Electronic unit: mm 160x365xh329
Printing head: mm 188x208xh234
Electric cable: m 2

In the images:
SWING 53.i - Coding & Marking Electronic Systems
